Price: $13.99
(as of Nov 18, 2024 17:16:01 UTC – Details)
Product Description
PiBOX India Video Game Capture Card, Ideal Choice For Gameplay, Live Broadcasting
PiBOX India Video Game Capture Card, Ideal Choice For Gameplay, Live Broadcasting
PiBOX India Newest USB Capture Card connects to your video source and computer, captures high-definition video up to 1080P 30FPS.
Real-Time Feedback: Go live on any platform in no time with PiBOX India Video capture units. Thanks to ultra-low-latency technology, shoot and produce within your favorite tools. High-intensity reproduction of video delicate colors, vivid picture with our unit.
Plug and Play with OBS: This capture card was easy to use; NO driver required, No external power supply, easily connect your DSLR, camcorder, or action Cam to your PC or Mac for game recording.
Wide Compatibility: The HDMI video capture adopted an advanced chip with wide compatibility. It support Windows, Ma OS X/ MAC, and Android operating system. It also supports most acquisition software, such as VLC / OBS / Amcap, etc
Heat vents: The heat vents on side helps dissipate the heat. The newly capture card with cool compact design, it would be an ideal partner for live broadcasting, gaming recording, teaching online and video conference etc.
Note:
1)On MacOS, Please use Quik time player APP to get it work
2)Computer hardware configuration requirements: CPU: PC i5-3400 or above; NB i7-3537U 3.0GHZ or above, Run memory: 4G RAM, Graphics card: PC NVIDIA GT630 or above; NC NVIDIA GT735M or above
(SEE SETUP PROCEDURE BELOW)
Capture your moments
With MACRO Silicon Chipset : There is no delay, no crash, no freeze, no blue screen. The video capture is a fast, familiar and economical way to share content in conference rooms and online meetings. Connect to presentations without software, just connect to a laptop or tablet via the capture card and cable to start sharing. And makes the live streaming, sharing and recording simple & fast. HD 1080P capture card will be a superb recording solution that ensures both video and audio quality.
Heat Dissipation Capture Device Aluminium Alloy with Vents
Heat Vents on USB Capture Card
The audio video capture card with heat dissipation vents can significantly reduce the heat. Better heat dissipation enhances stability and durability. No more worry about overheating while capturing video. You can capture a high-definition HDMI video signal of a signal channel. The game capture card is suitable for devices with HDMI output, such as PS4,Switch or Xbox.
Setup Procedure – How To Setup your USB 3.0 OBS Video Capture
How To Setup your USB 3.0 OBS Video Capture
1. Connect the UHD signal source to the HDMI input of the video capture with one HDMI cable(Not included)(Before purchasing, please make sure that your video source with an HDMI output port.
Step:2:- Setting up device Format
Step:2:- Setting up device Format
Device: USB Video / USB 3.0 VideoResolution/FPS Type: CustomResolution: 1920x1080FPS: 30 / Match Output FPS (Try the 30 if there are issues with frame rate) Video Format: Any / MJPEG(Default format: MKV)
Video Capture Setting- Audio Output
Audio Output Mode: Output desktop audio (WaveOut)
Mark the “√” in the blue box
Audio Device: (2-USB Digital Audio)
Video Capture Setting- Get Started
Video Capture Setting- Get Started
Click “Start Recording” to record the sources video and audio, files will be saved to the default folder
Click “Start Streaming” to begin you Live Broadcasting(Need to preset URL and Stream Key in the “Stream” tab of settings)
Computer Hardware Requirements
CPU Desktops: PC i5-3400 or above; Laptops: with 8th Gen I3 or higher yield better lag free Experience Graphics Card PC NVIDIA GT630 or above;NC NVIDIA GT735M or above Support Capture Software VLC/OBS/Amcap/Quick Time etc Support Operating Systems Windows 7/8/10 Macos Memory 8 GB Recommended
Capture Card Specifications
HDMI Input Resolution Max input resolution up to 3840×2160@30Hz Video Output Resolution Max output resolution up to 1920×1080@30Hz Video Output Format MJPEG/YUY2 Support Video Format 8/10/12bit Deep color Support AWG26 HDMI Cable Input up to 15 meters (Try shorter cables if you see impedance drops) Max Working Current 0.4A/5V DC Operating temperature range (-10 to + 55 ℃)
PiBOX India – Stunning 1080P Video Recording with Braided cable @ 30 HZ】Audio video capture cards can capture up to 3840×2160@60HZ High Definition Input, Output max resolution 1920×1080@30Hz only. It supports 1080High Quality Recording and live steaming. You can enjoy clear video for your recording, live streaming,broadcasting live. Enjoy the crystal clear image quality and ultra-high definition that our capture card brings to you, and will not drop frame when you are recording
⚡【High Frame Rate Image Recording】 Enjoy the ultra-high-definition picture quality brought by PiBOX India capture card, extremely low latency to meet your recording needs, and the frame rate will be higher at a specific pixel (Depending on the specific software application，Pixel frame rate will also change)
【Heat Dissipation Capture Device Aluminium Alloy】: The audio video capture card with heat dissipation vents can significantly reduce the heat. Better heat dissipation enhances stability and durability. No more worry about overheating while capturing video. You can capture a high-definition HDMI video signal of a signal channel. The game capture card is suitable for devices with HDMI output, such as PS4,Switch or Xbox.
⚡【Universal Compatibility】 This video capture device can be connected to the source HDMI interface devices (such as: PS3,PS4,NS switch, XBOX, computer, laptop, DVD,HD player etc). And it supports software such as: VLC, OBS, Amcap etc.Suitable for high definition acquisition, teaching recording, medical imaging, etc.
【Zero Latency Screen Share】: There is no delay, no crash, no freeze, no blue screen. The video capture is a fast, familiar and economical way to share content in conference rooms and online meetings. Connect to presentations without software, just connect to a laptop or tablet via the capture card and cable to start sharing. And makes the live streaming, sharing and recording simple & fast. HD 1080P capture card will be a superb recording solution that ensures both video and audio quality.
